Summary:
Langhui gasoline riding mower with a width of 24 “ (610mm). Power comes with LONXIN and BS, respectively. LONXIN engine, a well-known brand in China, has stable performance, moderate price and even has higher customer praise. So far, langhui 24 “ gasoline riding mower has been popular in Europe, South America for many years!
The four-stroke engine, with a steel chassis and 196 cc. Cutting height is central height adjustment. The cutting width is 61 cm, and the recommended area is 1500-2000 ㎡, and it has ball bearings.
Advantage:
1. The appearance design is simple, elegant and beautiful.
2. The qualified rate of transmission in market reach to be 99.99%.
3. Patented blade is better to cutting and crushing grass
4. The capacity of 100L&150L grass catcher can meet the needs of different customers.
5. One mowing width, different machine size design, save transportation costs, meet needs of different customers.
1 | Factory Model |
YH63R |
YH63RD |
2 | Engine type | Loncin 196cc 4.8KW/6.5HP Electric start Engine | Loncin 196cc 4.8KW/6.5HP Electric start Engine |
3 | Battery type | 12V 7AH | 12V 7AH |
4 | Max.Power at 3600 rpm (HP) | 4.8kw(6.5HP)/3600rpm | 4.8kw(6.5HP)/3600rpm |
5 | Petrol consumptiom ( l/h) | 0.9 | 0.9 |
6 | Driving speed | 1: 1.5 km/h | 1: 1.5 km/h |
7 | 2: 2.0 km/h | 2: 2.0 km/h | |
8 | 3: 3.0 km/h | 3: 3.0 km/h | |
9 | 4: 4.6 km/h | 4: 4.6 km/h | |
10 | R: 2.3 km/h | R: 2.3 km/h | |
11 | Cutting width | 610mm (24") | 610mm (24") |
12 | Cutting height | 35-75 (5 shifts) | 35-75 (5 shifts) |
13 | Wheel diameter | Front 10×3.5 | Front 10×3.5 |
14 | Back 13×5 | Back 13×5 | |
15 | Grass catcher | 150L | / |
16 | Working efficiency(m2/h) | up to 2600 | up to 2600 |
17 | Packing dimension LxWxH(cm) | 148×76.5×83 | 148×76.5×83 |
18 | Machine dimension LxWxH(cm) | 175×70×98 | 175×70×98 |
19 | Net weight(kg) | 115 | 110 |
20 | 20"/40"/40HQ Volume | 20/40/72 PCS | 20/40/72 PCS |
|
